دیتاشیت SN74LVC1G74DQER

SN74LVC1G74

مشخصات دیتاشیت

نام دیتاشیت SN74LVC1G74
حجم فایل 1286.325 کیلوبایت
نوع فایل pdf
تعداد صفحات 27

دانلود دیتاشیت SN74LVC1G74

SN74LVC1G74 Datasheet

مشخصات

  • RoHS: true
  • Category: Logic ICs/Flip Flops
  • Datasheet: Texas Instruments SN74LVC1G74DQER
  • Package: X2-SON-8(1x1.4)
  • Manufacturer: Texas Instruments
  • Number of Elements: 1
  • Operating Temperature: -40°C ~ 125°C (TA)
  • Function: Set(Preset) and Reset
  • Supplier Device Package: 8-X2SON (1.4x1.0)
  • Input Capacitance: 5pF
  • Current - Output High, Low: 32mA, 32mA
  • Voltage - Supply: 1.65V ~ 5.5V
  • Current - Quiescent (Iq): 10µA
  • Output Type: Differential
  • Mounting Type: Surface Mount
  • Type: D-Type
  • Packaging: Cut Tape (CT)
  • Number of Bits per Element: 1
  • Trigger Type: Positive Edge
  • Series: 74LVC
  • Max Propagation Delay @ V, Max CL: 4.4ns @ 5V, 50pF
  • Clock Frequency: 200MHz
  • Base Part Number: SN74LVC1G
  • Part Status: Active
  • Package / Case: 8-XFDFN
  • detail: Flip Flop 1 Element D-Type 1 Bit Positive Edge 8-XFDFN
