VND7012AY دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت VND7012AY	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/Power Distribution Switches
Datasheet: STMicroelectronics VND7012AYTR
Input Voltage: 4V~28V
Output Current: 60A
Number of Outputs: 2
Resistor On-State: 12mΩ
Operating Temperature -: -40°C~+150°C
Package: PowerSSO-36
Manufacturer: STMicroelectronics
Series: Automotive, AEC-Q100, VIPOWER™
Packaging: Cut Tape (CT)
Part Status: Active
Switch Type: General Purpose
Ratio - Input:Output: 1:1
Output Configuration: High Side
Output Type: N-Channel
Interface: On/Off
Voltage - Load: 4V ~ 28V
Voltage - Supply (Vcc/Vdd): Not Required
Current - Output (Max): 60A
Rds On (Typ): 12mOhm
Input Type: Non-Inverting
Features: Status Flag
Fault Protection: Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage, UVLO
Operating Temperature: -40°C ~ 150°C (TJ)
Mounting Type: Surface Mount
Supplier Device Package: PowerSSO-36
Package / Case: 36-PowerFSOP (0.295", 7.50mm Width)
Base Part Number: VND7012
detail: Power Switch/Driver 1:1 N-Channel 60A PowerSSO-36
