SN54LVC573A, SN74LVC573A دیتاشیت

SN54LVC573A, SN74LVC573A

مشخصات دیتاشیت

نام دیتاشیت SN54LVC573A, SN74LVC573A
حجم فایل 2425.279 کیلوبایت
نوع فایل pdf
تعداد صفحات 37

دانلود دیتاشیت SN54LVC573A, SN74LVC573A

دانلود دیتاشیت

سایر مستندات

SN74LVC573ADWR 38 pages

مشخصات فنی

  • RoHS: true
  • Series: 74LVC
  • Category: Logic ICs/Latches
  • Datasheet: Texas Instruments SN74LVC573ADBR
  • Logic Type: D-Typelocking Latch
  • Output Type: Tri-State
  • Sink Current: 24mA
  • Source Current: 24mA
  • Supply Voltage: 1.65V~3.6V
  • Propagation Delay: 2ns
  • OperatingTemperature: -40°C~+85°C
  • Package: SSOP-20-208mil
  • Manufacturer: Texas Instruments
  • Delay Time - Propagation: 2ns
  • Supplier Device Package: 20-SSOP
  • Package / Case: 20-SSOP (0.209", 5.30mm Width)
  • Circuit: 8:8
  • Mounting Type: Surface Mount
  • Base Part Number: SN74LVC57
  • Packaging: Cut Tape (CT)
  • Voltage - Supply: 1.65V ~ 3.6V
  • Current - Output High, Low: 24mA, 24mA
  • Independent Circuits: 1
  • Operating Temperature: -40°C ~ 85°C
  • Part Status: Active
  • detail: D-Type Transparent Latch 1 Channel 8:8 IC Tri-State 20-SSOP
