دیتاشیت LP3985IM5-3.2/NOPB

LP3985

مشخصات دیتاشیت

نام دیتاشیت LP3985
حجم فایل 1017.402 کیلوبایت
نوع فایل pdf
تعداد صفحات 17

دانلود دیتاشیت LP3985

LP3985 Datasheet

مشخصات

  • Control Features: Enable
  • Base Part Number: LP3985
  • Package / Case: SC-74A, SOT-753
  • Current - Supply (Max): 250µA
  • Part Status: Obsolete
  • Current - Output: 150mA
  • PSRR: 50dB ~ 40dB (1kHz ~ 10kHz)
  • Series: -
  • Voltage - Output (Min/Fixed): 3.2V
  • Mounting Type: Surface Mount
  • Number of Regulators: 1
  • Current - Quiescent (Iq): 150µA
  • Output Configuration: Positive
  • Voltage Dropout (Max): 0.1V @ 150mA
  • Operating Temperature: -40°C ~ 125°C
  • Supplier Device Package: SOT-23-5
  • Protection Features: Over Current, Over Temperature, Short Circuit
  • Manufacturer: Texas Instruments
  • Voltage - Input (Max): 6V
  • Output Type: Fixed
  • Packaging: Cut Tape (CT)
  • Voltage - Output (Max): -
  • detail: Linear Voltage Regulator IC 1 Output 150mA SOT-23-5
