TDA75610S-ZST Datasheet

TDA75610S

Datasheet specifications

Datasheet's name TDA75610S
File size 946.84 KB
File type pdf
Number of pages 42

Download Datasheet TDA75610S

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Type: Class AB
  • Output Type: 4-Channel (Quad)
  • Max Output Power x Channels @ Load: 45W x 4 @ 4Ohm
  • Voltage - Supply: 6V ~ 18V
  • Features: Mute, Standby
  • Mounting Type: Surface Mount
  • Operating Temperature: -40°C ~ 105°C (TA)
  • Supplier Device Package: PowerSO-36
  • Package / Case: PowerSO-36 Exposed Bottom Pad
  • Base Part Number: TDA7561
  • detail: Amplifier IC 4-Channel (Quad) Class AB PowerSO-36
