CSD16410Q5A دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت CSD16410Q5A	دانلود دیتاشیت

RoHS: true
Category: Triode/MOS Tube/Transistor/MOSFETs
Datasheet: Texas Instruments CSD16410Q5A
Package: VSON-CLIP-8(5x6)
Manufacturer: Texas Instruments
FET Type: N-Channel
Vgs(th) (Max) @ Id: 2.3V @ 250µA
Base Part Number: CSD164
Supplier Device Package: 8-VSONP (5x6)
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Input Capacitance (Ciss) (Max) @ Vds: 740pF @ 12.5V
FET Feature: -
Drain to Source Voltage (Vdss): 25V
Current - Continuous Drain (Id) @ 25°C: 16A (Ta), 59A (Tc)
Mounting Type: Surface Mount
Rds On (Max) @ Id, Vgs: 8.5mOhm @ 17A, 10V
Packaging: Cut Tape (CT)
Operating Temperature: -55°C ~ 150°C (TJ)
Series: NexFET™
Package / Case: 8-PowerTDFN
Gate Charge (Qg) (Max) @ Vgs: 5nC @ 4.5V
Vgs (Max): +16V, -12V
Part Status: Active
Power Dissipation (Max): 3W (Ta)
Technology: MOSFET (Metal Oxide)
detail: N-Channel 25V 16A (Ta), 59A (Tc) 3W (Ta) Surface Mount 8-VSONP (5x6)
