LD29300P2M18R دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
LD29300P2M18R
|
|
حجم فایل
|
520.488
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
26
|
مشخصات فنی
-
Manufacturer:
STMicroelectronics
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Obsolete
-
Output Configuration:
Positive
-
Output Type:
Fixed
-
Number of Regulators:
1
-
Voltage - Input (Max):
30V
-
Voltage - Output (Min/Fixed):
1.8V
-
Voltage - Output (Max):
-
-
Voltage Dropout (Max):
0.7V @ 3A
-
Current - Output:
3A
-
Current - Quiescent (Iq):
180µA
-
Current - Supply (Max):
100mA
-
PSRR:
72dB (120Hz)
-
Control Features:
Enable
-
Protection Features:
Over Current, Over Temperature
-
Operating Temperature:
-40°C ~ 125°C
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-263-6, D²Pak (5 Leads + Tab), TO-263BA
-
Supplier Device Package:
P2PAK-4
-
Base Part Number:
LD29300
-
detail:
Linear Voltage Regulator IC 1 Output 3A P2PAK-4
