SM2T3V3A دیتاشیت

SM2T3V3A

مشخصات دیتاشیت

نام دیتاشیت SM2T3V3A
حجم فایل 40.502 کیلوبایت
نوع فایل pdf
تعداد صفحات 6

مشاهده دیتاشیت SM2T3V3A

دانلود دیتاشیت

سایر مستندات

SM2T3V3A 6 pages

مشخصات فنی

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/TVS
  • Datasheet: STMicroelectronics SM2T3V3A
  • Breakdown Voltage: 3.6V
  • Unidirectional Channels: 1
  • Maximum Clamping Voltage: 6.5V
  • Reverse Leakage Current (Ir): 500uA
  • Reverse Stand-Off Voltage (Vrwm): 3.3V
  • Peak Pulse Current (Ipp)@10/1000us: 25A
  • Peak Pulse Power Dissipation (Ppp)@10/1000us: 200W
  • Package: DO-216AA
  • Manufacturer: STMicroelectronics
  • Series: SM2T, TRANSIL™
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Type: Zener
  • Voltage - Reverse Standoff (Typ): 3.3V
  • Voltage - Breakdown (Min): 3.6V
  • Voltage - Clamping (Max) @ Ipp: 6.8V
  • Current - Peak Pulse (10/1000µs): 30A
  • Power - Peak Pulse: 200W
  • Power Line Protection: No
  • Applications: General Purpose
  • Capacitance @ Frequency: 2500pF @ 1MHz
  • Operating Temperature: -
  • Mounting Type: Surface Mount
  • Package / Case: DO-216AA
  • Supplier Device Package: DO-216AA
  • Base Part Number: SM2T
  • detail: 6.8V Clamp 30A Ipp Tvs Diode Surface Mount DO-216AA
