TS3A5017QRGYRQ1 دیتاشیت

TS3A5017QRGYRQ1

مشخصات دیتاشیت

نام دیتاشیت TS3A5017QRGYRQ1
حجم فایل 58.852 کیلوبایت
نوع فایل pdf
تعداد صفحات 24

مشاهده دیتاشیت TS3A5017QRGYRQ1

دانلود دیتاشیت

سایر مستندات

مستندات دیگری یافت نشد!

مشخصات فنی

  • RoHS: true
  • Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
  • Datasheet: Texas Instruments TS3A5017QRGYRQ1
  • Turn-on time: 9.5ns
  • Turn-off time: 3.5ns
  • Supply Voltage: 2.3V~3.6V
  • Switch Circuit: 单刀四掷(SP4T)
  • Number of Channels: 2
  • On-State Resistance (Max): 11Ω
  • Package: VQFN-16
  • Manufacturer: Texas Instruments
  • Voltage - Supply, Single (V+): 2.3V ~ 3.6V
  • Multiplexer/Demultiplexer Circuit: 4:1
  • Current - Leakage (IS(off)) (Max): 50nA (Typ)
  • Crosstalk: -69dB @ 1MHz
  • Voltage - Supply, Dual (V±): -
  • Packaging: Cut Tape (CT)
  • Channel-to-Channel Matching (ΔRon): 1Ohm
  • Charge Injection: 5pC
  • Supplier Device Package: 16-VQFN (4x3.5)
  • -3db Bandwidth: 165MHz
  • Base Part Number: TS3A50
  • Mounting Type: Surface Mount
  • Channel Capacitance (CS(off), CD(off)): 4.5pF, 19pF
  • Switch Time (Ton, Toff) (Max): 9.5ns, 3.5ns
  • Operating Temperature: -40°C ~ 125°C (TA)
  • Number of Circuits: 2
  • Series: Automotive, AEC-Q100
  • Package / Case: 16-VFQFN Exposed Pad
  • Part Status: Active
  • detail: 2 Circuit IC Switch 4:1 11Ohm (Typ) 16-VQFN (4x3.5)
