TPD4E6B06DPWR دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت TPD4E6B06DPWR	دانلود دیتاشیت

RoHS: true
Category: TVS/Fuse/Board Level Protection/TVS
Datasheet: Texas Instruments TPD4E6B06DPWR
Breakdown Voltage: 6V
Bidirectional Channels: 4
Maximum Clamping Voltage: 13V
Reverse Stand-Off Voltage (Vrwm): 5.5V@Max
Peak Pulse Current (Ipp)@10/1000μs: 3A@8/20us
Peak Pulse Power Dissipation (Ppp)@10/1000μs: 40W
Package: X2-SON-4
Manufacturer: Texas Instruments
Type: Zener
Supplier Device Package: 4-X2SON (0.8x0.8)
Current - Peak Pulse (10/1000µs): 3A (8/20µs)
Applications: General Purpose
Voltage - Reverse Standoff (Typ): 5.5V (Max)
Voltage - Breakdown (Min): 6V
Voltage - Clamping (Max) @ Ipp: 13V (Typ)
Capacitance @ Frequency: -
Mounting Type: Surface Mount
Power Line Protection: No
Base Part Number: TPD4E
Packaging: Cut Tape (CT)
Operating Temperature: -40°C ~ 125°C (TA)
Series: -
Power - Peak Pulse: 40W
Package / Case: 4-XFDFN Exposed Pad
Part Status: Active
detail: 13V (Typ) Clamp 3A (8/20µs) Ipp Tvs Diode Surface Mount 4-X2SON (0.8x0.8)
