- دیتاشیت SN74F32DR
SN74F32DR دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | SN74F32DR |
|---|---|
| حجم فایل | 59.895 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 17 |
دانلود دیتاشیت SN74F32DR |
دانلود دیتاشیت |
|---|
سایر مستندات
SN54F32, SN74F32 19 pages
مشخصات فنی
- RoHS: true
- Series: 74F
- Category: Logic ICs/Gates
- Datasheet: Texas Instruments SN74F32DR
- Sink Current: 20mA
- Source Current: 1mA
- Supply Voltage: 4.5V~5.5V
- Logic Gate Type: ORGate
- Number of Channels: 4
- Low Level Range (VIL): 0.8V
- Low Level Range (VOL): -
- Operating Temperature: 0°C~+70°C
- High Level Range (VIH): 2V
- High Level Range (VOH): -
- Propagation Delay Time: -
- Quiescent Current (Max): -
- Package: SOP-14
- Manufacturer: Texas Instruments
- Logic Level - High: 2V
- Base Part Number: SN74F32
- Supplier Device Package: 14-SOIC
- Logic Level - Low: 0.8V
- Package / Case: 14-SOIC (0.154", 3.90mm Width)
- Current - Output High, Low: 1mA, 20mA
- Features: -
- Mounting Type: Surface Mount
- Packaging: Cut Tape (CT)
- Voltage - Supply: 4.5V ~ 5.5V
- Number of Circuits: 4
- Max Propagation Delay @ V, Max CL: 5.6ns @ 5V, -
- Number of Inputs: 2
- Part Status: Active
- Logic Type: OR Gate
- detail: OR Gate IC 4 Channel 14-SOIC
