STIEC45-xxA(C)S Datasheet

STIEC45-xxA(C)S

Datasheet specifications

Datasheet's name STIEC45-xxA(C)S
File size 1129.16 KB
File type pdf
Number of pages 11

Download Datasheet STIEC45-xxA(C)S

Download Datasheet

Other documentations

STIEC45-30AS 11 pages

Technical specifications

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/TVS
  • Datasheet: STMicroelectronics STIEC45-24AS
  • Breakdown Voltage: 26.7V
  • Unidirectional Channels: 1
  • Maximum Clamping Voltage: 42V
  • Reverse Leakage Current (Ir): 0.2uA
  • Reverse Stand-Off Voltage (Vrwm): 24V
  • Peak Pulse Current (Ipp)@10/1000μs: 500A@8/20us
  • Peak Pulse Power Dissipation (Ppp)@10/1000μs: -
  • Package: SMC(DO-214AB)
  • Manufacturer: STMicroelectronics
  • Series: STIEC, TRANSIL™
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Type: Zener
  • Voltage - Reverse Standoff (Typ): 24V
  • Voltage - Breakdown (Min): 26.7V
  • Voltage - Clamping (Max) @ Ipp: 42V
  • Current - Peak Pulse (10/1000µs): 500A (8/20µs)
  • Power - Peak Pulse: -
  • Power Line Protection: No
  • Applications: General Purpose
  • Capacitance @ Frequency: -
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: DO-214AB, SMC
  • Supplier Device Package: SMC (DO-214AB)
  • Base Part Number: STIEC45
  • detail: 42V Clamp 500A (8/20µs) Ipp Tvs Diode Surface Mount SMC (DO-214AB)
