TLV704345DBVR 数据手册
其他文档
TLV704xx 23 pages
技术规格
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments TLV704345DBVR
- Output Current: 150mA
- Output Voltage: 3.45V
- Dropout Voltage: 1.1V@(100mA)
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 24V
- Operating Temperature: -40°C~+125°C@(Tj)
- Quiescent Current (Ground Current): 4.5uA
- Power Supply Rejection Ratio (PSRR): 60dB@(100kHz)
- Package: SOT-23-5
- Manufacturer: Texas Instruments
- Series: -
- Voltage - Output (Max): -
- Output Configuration: Positive
- Output Type: Fixed
- Voltage Dropout (Max): 1.1V @ 100mA
- Packaging: Cut Tape (CT)
- Voltage - Output (Min/Fixed): 3.45V
- Protection Features: -
- PSRR: 60dB (100kHz)
- Supplier Device Package: SOT-23-5
- Current - Quiescent (Iq): 4.5µA
- Base Part Number: TLV704
- Mounting Type: Surface Mount
- Number of Regulators: 1
- Voltage - Input (Max): 24V
- Current - Output: 150mA
- Part Status: Active
- Current - Supply (Max): 5.5µA
- Control Features: -
- Package / Case: SC-74A, SOT-753
- detail: Linear Voltage Regulator IC 1 Output 150mA SOT-23-5
