دیتاشیت SN74ALS04BNSR

SN(54,74)(ALS,AS)04(B)

مشخصات دیتاشیت

نام دیتاشیت SN(54,74)(ALS,AS)04(B)
حجم فایل 1215.53 کیلوبایت
نوع فایل pdf
تعداد صفحات 21

دانلود دیتاشیت SN(54,74)(ALS,AS)04(B)

SN(54,74)(ALS,AS)04(B) Datasheet

مشخصات

  • RoHS: true
  • Series: 74ALS
  • Category: Logic ICs/Inverters
  • Datasheet: Texas Instruments SN74ALS04BNSR
  • Sink Current: 8mA
  • Source Current: 400uA
  • Number of Inputs: 1
  • Number of Circuits: 6
  • Supply Current (Max): 1.1mA
  • Low level range (VIL): 0.8V
  • Max Propagation Delay: 11ns@5V,50pF
  • Operating Temperature: 0°C~+70°C
  • High level range (VIH): 2V
  • Supply Voltage(Single): 4.5V~5.5V
  • Package: SO-14
  • Manufacturer: Texas Instruments
  • Logic Level - High: 2V
  • Base Part Number: SN74ALS0
  • Supplier Device Package: 14-PDIP
  • Logic Level - Low: 0.8V
  • Package / Case: 14-DIP (0.300", 7.62mm)
  • Current - Output High, Low: 400µA, 8mA
  • Features: -
  • Mounting Type: Through Hole
  • Packaging: Tube
  • Voltage - Supply: 4.5V ~ 5.5V
  • Max Propagation Delay @ V, Max CL: 11ns @ 5V, 50pF
  • Part Status: Active
  • Logic Type: Inverter
  • detail: Inverter IC 6 Channel 14-PDIP
