TS5A623157 دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت TS5A623157	دانلود دیتاشیت

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: Texas Instruments TS5A623157DGSR
Switch Circuit: -
Package: MSOP-10
Manufacturer: Texas Instruments
Voltage - Supply, Single (V+): 1.65V ~ 5.5V
Multiplexer/Demultiplexer Circuit: 2:1
Current - Leakage (IS(off)) (Max): 20nA
Crosstalk: -61dB @ 10MHz
Voltage - Supply, Dual (V±): -
Packaging: Cut Tape (CT)
Channel-to-Channel Matching (ΔRon): 100mOhm
Charge Injection: 110pC
Supplier Device Package: 10-VSSOP
On-State Resistance (Max): 10Ohm
-3db Bandwidth: 371MHz
Base Part Number: TS5A623
Mounting Type: Surface Mount
Channel Capacitance (CS(off), CD(off)): 5pF
Switch Time (Ton, Toff) (Max): 5ns, 3.4ns
Operating Temperature: -40°C ~ 85°C (TA)
Number of Circuits: 2
Series: -
Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
Part Status: Active
detail: 2 Circuit IC Switch 2:1 10Ohm 10-VSSOP
