دیتاشیت TL3843DR-8
مشخصات دیتاشیت
| نام دیتاشیت |
TL284x, TL384x
|
| حجم فایل |
1505.667
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
28
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/AC-DC Controllers & Regulators
-
Topology:
Boost;Flyback;Forward
-
Datasheet:
Texas Instruments TL3843DR-8
-
Supply Voltage:
7.6V~30V
-
Switching Frequency:
500kHz
-
Package:
SOP-8
-
Manufacturer:
Texas Instruments
-
Number of Outputs:
1
-
Voltage - Supply (Vcc/Vdd):
7.6V ~ 30V
-
Base Part Number:
TL3843
-
Operating Temperature:
0°C ~ 70°C (TA)
-
Package / Case:
14-SOIC (0.154", 3.90mm Width)
-
Output Configuration:
Positive
-
Series:
-
-
Supplier Device Package:
14-SOIC
-
Frequency - Switching:
Up to 500kHz
-
Part Status:
Active
-
Mounting Type:
Surface Mount
-
Control Features:
Frequency Control
-
Clock Sync:
No
-
Serial Interfaces:
-
-
Function:
Step-Up, Step-Up/Step-Down
-
Duty Cycle (Max):
97%
-
Packaging:
Cut Tape (CT)
-
Synchronous Rectifier:
No
-
Output Type:
Transistor Driver
-
Output Phases:
1
-
detail:
Boost, Flyback, Forward Regulator Positive Output Step-Up, Step-Up/Step-Down DC-DC Controller IC 14-SOIC
