IPS160H دیتاشیت

IPS160H

مشخصات دیتاشیت

نام دیتاشیت IPS160H
حجم فایل 913.38 کیلوبایت
نوع فایل pdf
تعداد صفحات 26

مشاهده دیتاشیت IPS160H

دانلود دیتاشیت

سایر مستندات

IPS160H 26 pages

IPS160HTR 26 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Power Distribution Switches
  • Datasheet: STMicroelectronics IPS160HTR
  • Input Voltage: 8V~60V
  • Output Current: 2.5A
  • Number of Outputs: 1
  • Resistor On-State: 60mΩ
  • Operating Temperature -: -40°C~+125°C
  • Package: PowerSSO-12
  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Switch Type: General Purpose
  • Ratio - Input:Output: 1:1
  • Output Configuration: High Side
  • Output Type: P-Channel
  • Interface: On/Off
  • Voltage - Load: 8V ~ 60V
  • Voltage - Supply (Vcc/Vdd): Not Required
  • Current - Output (Max): 2.5A
  • Rds On (Typ): 60mOhm
  • Input Type: Non-Inverting
  • Features: -
  • Fault Protection: Over Temperature, UVLO
  • Operating Temperature: -40°C ~ 125°C (TJ)
  • Mounting Type: Surface Mount
  • Supplier Device Package: PowerSSO-12
  • Package / Case: 12-PowerLSOP (0.154", 3.90mm Width)
  • Base Part Number: IPS16
  • detail: Power Switch/Driver 1:1 P-Channel 2.5A PowerSSO-12
