دیتاشیت LP5910-1.8DRVT
مشخصات دیتاشیت
| نام دیتاشیت | LP5910 Datasheet |
|---|---|
| حجم فایل | 1906.873 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 35 |
دانلود دیتاشیت LP5910 Datasheet |
LP5910 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments LP5910-1.8DRVT
- Output Type: Fixed
- Output Current: 300mA
- Output Voltage: 1.8V
- Dropout Voltage: 180mV@(300mA)
- Output Polarity: Positive
- Number of Outputs: 1
- Maximum Input Voltage: 3.3V
- Operating Temperature: -40°C~+125°C@(Tj)
- Quiescent Current (Ground Current): 25uA
- Power Supply Rejection Ratio (PSRR): 80dB@(100Hz),25dB@(2MHz)
- Package: DFN-6(2x2)
- Manufacturer: Texas Instruments
- Series: -
- Voltage - Output (Max): -
- Output Configuration: Positive
- Voltage Dropout (Max): 0.37V @ 300mA
- Packaging: Cut Tape (CT)
- Voltage - Output (Min/Fixed): 1.8V
- Protection Features: Over Temperature, Reverse Polarity, Short Circuit
- PSRR: 80dB ~ 25dB (100Hz ~ 2MHz)
- Supplier Device Package: 6-WSON (2x2)
- Current - Quiescent (Iq): 25µA
- Base Part Number: LP5910
- Mounting Type: Surface Mount
- Number of Regulators: 1
- Voltage - Input (Max): 3.3V
- Current - Output: 300mA
- Part Status: Active
- Current - Supply (Max): 350µA
- Control Features: Enable
- Package / Case: 6-WDFN Exposed Pad
- detail: Linear Voltage Regulator IC 1 Output 300mA 6-WSON (2x2)
