SN74LVC2GU04YZPR دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
SN74LVC2GU04YZPR
|
|
حجم فایل
|
75.255
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
19
|
مشخصات فنی
-
RoHS:
true
-
Series:
74LVC
-
Category:
Logic ICs/Inverters
-
Datasheet:
Texas Instruments SN74LVC2GU04YZPR
-
Sink Current:
32mA
-
Source Current:
32mA
-
Number of Inputs:
2
-
Number of Circuits:
2
-
Supply Current (Max):
10uA
-
Low level range (VIL):
0.41V~1.38V
-
Max Propagation Delay:
3ns@5V,50pF
-
Operating Temperature:
-40°C~+85°C
-
High level range (VIH):
1.24V~4.13V
-
Supply Voltage(Single):
1.65V~5.5V
-
Package:
BGA-6
-
Manufacturer:
Texas Instruments
-
Logic Level - High:
-
-
Base Part Number:
SN74LVC2G
-
Supplier Device Package:
6-DSBGA, 6-WCSP (1.4x0.9)
-
Logic Level - Low:
-
-
Package / Case:
6-XFBGA, DSBGA
-
Current - Quiescent (Max):
10µA
-
Current - Output High, Low:
32mA, 32mA
-
Features:
-
-
Mounting Type:
Surface Mount
-
Packaging:
Cut Tape (CT)
-
Voltage - Supply:
1.65V ~ 5.5V
-
Max Propagation Delay @ V, Max CL:
3ns @ 5V, 50pF
-
Part Status:
Active
-
Logic Type:
Inverter
-
detail:
Inverter IC 2 Channel 6-DSBGA, 6-WCSP (1.4x0.9)
