TPS7B6933DBVR دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت TPS7B6933DBVR	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/Linear Voltage Regulators (LDO)
Datasheet: Texas Instruments TPS7B6933DBVR
Output Current: 150mA
Output Voltage: 12V~12V
Dropout Voltage: 0.8V@(100mA)
Output Polarity: positive
Number of Outputs: 1
Maximum Input Voltage: 40V
Operating Temperature: -40°C~+105°C
Quiescent Current (Ground Current): 25uA
Power Supply Rejection Ratio (PSRR): 60dB@(100Hz)
Package: SOT-23-5
Manufacturer: Texas Instruments
Base Part Number: TPS7B6
Supplier Device Package: SOT-23-5
Voltage - Output (Max): -
Output Configuration: Positive
Current - Quiescent (Iq): 25µA
Output Type: Fixed
PSRR: 60dB (100Hz)
Voltage Dropout (Max): 0.8V @ 100mA
Number of Regulators: 1
Mounting Type: Surface Mount
Packaging: Cut Tape (CT)
Voltage - Output (Min/Fixed): 3.3V
Protection Features: Over Current, Over Temperature, Short Circuit, Under Voltage Lockout (UVLO)
Series: -
Voltage - Input (Max): 40V
Current - Output: 150mA
Part Status: Active
Package / Case: SC-74A, SOT-753
Control Features: -
detail: Linear Voltage Regulator IC 1 Output 150mA SOT-23-5
