دیتاشیت LP3986TL-2525/NOPB

LP3986

مشخصات دیتاشیت

نام دیتاشیت LP3986
حجم فایل 1035.998 کیلوبایت
نوع فایل pdf
تعداد صفحات 18

دانلود دیتاشیت LP3986

LP3986 Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Texas Instruments LP3986TL-2525/NOPB
  • Output Current: 150mA
  • Output Voltage: 2.5V
  • Dropout Voltage: 0.1V@(150mA)
  • Output Polarity: positive
  • Number of Outputs: 2
  • Maximum Input Voltage: 6V
  • Operating Temperature: -40°C~+125°C
  • Quiescent Current (Ground Current): 130uA
  • Package: BGA-8
  • Manufacturer: Texas Instruments
  • Series: -
  • Voltage - Output (Max): -
  • Output Configuration: Positive
  • Output Type: Fixed
  • Voltage Dropout (Max): 0.1V @ 150mA
  • Packaging: Cut Tape (CT)
  • Voltage - Output (Min/Fixed): 2.5V
  • Protection Features: Over Current, Over Temperature, Short Circuit
  • PSRR: 60dB ~ 50dB (1kHz ~ 10kHz)
  • Supplier Device Package: 8-DSBGA (1.56x1.56)
  • Current - Quiescent (Iq): 130µA
  • Base Part Number: LP3986
  • Mounting Type: Surface Mount
  • Number of Regulators: 2
  • Voltage - Input (Max): 6V
  • Current - Output: 150mA
  • Part Status: Active
  • Current - Supply (Max): 320µA
  • Control Features: Enable
  • Package / Case: 8-WFBGA, DSBGA
  • detail: Linear Voltage Regulator IC 2 Output 150mA 8-DSBGA (1.56x1.56)
