دیتاشیت LM336BMX-2.5/NOPB
مشخصات دیتاشیت
| نام دیتاشیت | LM136-2.5, LM236-2.5, LM336-2.5 |
|---|---|
| حجم فایل | 727.351 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 14 |
دانلود دیتاشیت LM136-2.5, LM236-2.5, LM336-2.5 |
LM136-2.5, LM236-2.5, LM336-2.5 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Voltage References
- Datasheet: Texas Instruments LM336BMX-2.5/NOPB
- Tolerance: ±2%
- Output Type: Fixed
- Input Voltage: -
- Output Current: 10mA
- Output Voltage: 2.49V
- Reference Type: parallel connection
- Supply Current: -
- Noise - 10Hz to 10kHz: -
- Operating Temperature: 0°C~+70°C@(Ta)
- Noise - 1/10Hz to 10Hz: -
- Temperature Coefficient: -
- Package: SOP-8
- Manufacturer: Texas Instruments
- Series: -
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Current - Cathode: 400µA
- Current - Supply: -
- Current - Output: 10mA
- Noise - 0.1Hz to 10Hz: -
- Part Status: Discontinued at Digi-Key
- Mounting Type: Surface Mount
- Voltage - Input: -
- Voltage - Output (Min/Fixed): 2.49V
- Packaging: Cut Tape (CT)
- Base Part Number: LM336
- Supplier Device Package: 8-SOIC
- detail: Shunt Voltage Reference IC ±2% 8-SOIC
