TLV1704AQPWRQ1 دیتاشیت

TLV1704AQPWRQ1

مشخصات دیتاشیت

نام دیتاشیت TLV1704AQPWRQ1
حجم فایل 111.989 کیلوبایت
نوع فایل pdf
تعداد صفحات 29

دانلود دیتاشیت TLV1704AQPWRQ1

دانلود دیتاشیت

سایر مستندات

TLV170x-Q1 Datasheet 29 pages

مشخصات فنی

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Comparators
  • Datasheet: Texas Instruments TLV1701AQDCKRQ1
  • Output Type: Push Pull
  • Supply Voltage: 2.2V;1.1V~36V;18V
  • Number of Elements: -
  • Operating Temperature: -40°C~+125°C
  • Input Bias Current (Ib): 0.015uA
  • Input Offset Voltage (Vos): 2.5mV
  • Input Hysteresis Voltage (Vhys): -
  • Common Mode Rejection Ratio (CMRR): 75dB
  • Package: SC-70-5
  • Manufacturer: Texas Instruments
  • Voltage - Input Offset (Max): 2.5mV @ 36V
  • Type: General Purpose
  • Supplier Device Package: SC-70-5
  • Mounting Type: Surface Mount
  • Current - Quiescent (Max): 75µA
  • Propagation Delay (Max): 560ns (Typ)
  • Current - Input Bias (Max): 15nA @ 36V
  • Base Part Number: TLV170
  • Packaging: Cut Tape (CT)
  • Hysteresis: -
  • Series: Automotive, AEC-Q100
  • Current - Output (Typ): 20mA @ 36V
  • CMRR, PSRR (Typ): -
  • Part Status: Active
  • Package / Case: 5-TSSOP, SC-70-5, SOT-353
  • Voltage - Supply, Single/Dual (±): 2.2V, ±1.1V ~ 36V, ±18V
  • detail: Comparator General Purpose Open-Collector, Rail-to-Rail SC-70-5
