LMC6772(Q) دیتاشیت

LMC6772(Q)

مشخصات دیتاشیت

نام دیتاشیت LMC6772(Q)
حجم فایل 1450.399 کیلوبایت
نوع فایل pdf
تعداد صفحات 28

دانلود دیتاشیت LMC6772(Q)

دانلود دیتاشیت

سایر مستندات

LMC6772AIMX/NOPB 28 pages

مشخصات فنی

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Comparators
  • Datasheet: Texas Instruments LMC6772QMM/NOPB
  • Output Type: Open Drain
  • Supply Voltage: 2.7V~15V;1.35V~7.5V
  • Number of Elements: -
  • Operating Temperature: -40°C~+125°C
  • Input Bias Current (Ib): 0.04pA
  • Input Offset Voltage (Vos): 10mV
  • Input Hysteresis Voltage (Vhys): -
  • Common Mode Rejection Ratio (CMRR): 75dB
  • Package: VSSOP-8
  • Manufacturer: Texas Instruments
  • Voltage - Input Offset (Max): 10mV @ 5V
  • Type: General Purpose
  • Supplier Device Package: 8-VSSOP
  • Mounting Type: Surface Mount
  • Current - Quiescent (Max): 20µA
  • Propagation Delay (Max): 10µs
  • Current - Input Bias (Max): 0.04pA @ 5V
  • Base Part Number: LMC6772
  • Packaging: Cut Tape (CT)
  • Hysteresis: -
  • Series: Automotive, AEC-Q100
  • Current - Output (Typ): 30mA
  • CMRR, PSRR (Typ): 75dB CMRR, 80dB PSRR
  • Part Status: Active
  • Package / Case: 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
  • Voltage - Supply, Single/Dual (±): 2.7V ~ 15V, ±1.35V ~ 7.5V
  • detail: Comparator General Purpose Open Drain 8-VSSOP
