دیتاشیت EMIF08-LCD04M16

مشخصات دیتاشیت

دانلود دیتاشیت EMIF08-LCD04M16	EMIF08-LCD04M16 Datasheet

RoHS: true
Category: Bead/Filter/EMI Optimization/EMI Filters (LC, RC Networks)
Datasheet: STMicroelectronics EMIF08-LCD04M16
Inductance: 12nH
Resistance: -
Capacitance: 18pF
Filter Order: 3
Rated Current: -
ESD Protection: Yes
DC Rated Voltage: -
Attenuation Value: -35dB@900MHz~2GHz
Number of Channels: 8
OperatingTemperature: -40°C~+85°C
Frequency - Cutoff or Center: -
Package: QFN
Manufacturer: STMicroelectronics
Series: IPAD™
Packaging: Cut Tape (CT)
Part Status: Active
Type: Low Pass
Technology: LC (Pi)
Center / Cutoff Frequency: 400MHz (Cutoff)
Resistance - Channel (Ohms): 12.5
Values: L = 12nH, C = 18pF
Operating Temperature: -40°C ~ 85°C
Applications: Data Lines for Mobile Devices
Voltage - Rated: -
Mounting Type: Surface Mount
Package / Case: 16-UFDFN Exposed Pad
Size / Dimension: 0.130" L x 0.053" W (3.30mm x 1.35mm)
Height: 0.022" (0.55mm)
Base Part Number: EMIF08
detail: LC (Pi) EMI Filter 3rd Order Low Pass 8 Channel L = 12nH, C = 18pF 16-UFDFN Exposed Pad
