STPS40M60CT دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
STPS40M60C
|
|
حجم فایل
|
128.615
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
10
|
مشخصات فنی
-
Manufacturer:
STMicroelectronics
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
Diode Configuration:
1 Pair Common Cathode
-
Diode Type:
Schottky
-
Voltage - DC Reverse (Vr) (Max):
60V
-
Current - Average Rectified (Io) (per Diode):
20A
-
Voltage - Forward (Vf) (Max) @ If:
595mV @ 20A
-
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
-
Current - Reverse Leakage @ Vr:
110µA @ 60V
-
Operating Temperature - Junction:
150°C (Max)
-
Mounting Type:
Through Hole
-
Package / Case:
TO-220-3
-
Supplier Device Package:
TO-220AB
-
Base Part Number:
STPS40
-
detail:
Diode Array 1 Pair Common Cathode Schottky 60V 20A Through Hole TO-220-3
