دیتاشیت OPA4348AIDR
مشخصات دیتاشیت
| نام دیتاشیت | OPA348, 2348, 4348 |
|---|---|
| حجم فایل | 1960.774 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 47 |
دانلود دیتاشیت OPA348, 2348, 4348 |
OPA348, 2348, 4348 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Operational Amplifier/Comparator/Operational Amplifier
- Datasheet: Texas Instruments OPA4348AIDR
- Rail to Rail: 轨到轨
- -3db Bandwidth: -
- Output Current: 10mA
- Supply Current: 45uA
- Number of Circuits: 4
- Operating Temperature: -40°C~+125°C
- Current - Input Bias(Ib): 0.5pA
- Gain Bandwidth Product(GBP): 1MHz
- Package: SOP-14
- Manufacturer: Texas Instruments
- Current - Output / Channel: 10mA
- Current - Supply: 45µA
- Voltage - Input Offset: 1mV
- Supplier Device Package: 14-SOIC
- Slew Rate: 0.5V/µs
- Amplifier Type: General Purpose
- Mounting Type: Surface Mount
- Output Type: Rail-to-Rail
- Current - Input Bias: 0.5pA
- Gain Bandwidth Product: 1MHz
- Base Part Number: OPA4348
- Packaging: Cut Tape (CT)
- Series: -
- Package / Case: 14-SOIC (0.154", 3.90mm Width)
- Part Status: Active
- Voltage - Supply, Single/Dual (±): 2.1V ~ 5.5V
- detail: General Purpose Amplifier 4 Circuit Rail-to-Rail 14-SOIC
