دیتاشیت STM32F102RBT6
مشخصات دیتاشیت
| نام دیتاشیت | STM32F102x(8,B) Datasheet |
|---|---|
| حجم فایل | 1591.902 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 81 |
دانلود دیتاشیت STM32F102x(8,B) Datasheet |
STM32F102x(8,B) Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- EEPROM: -
- CPU Core: ARM Cortex-M3
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: 16KB
- Watchdog: Yes
- ADC (Bit): 12bit
- DAC (Bit): -
- Datasheet: STMicroelectronics STM32F102RBT6
- PWM (Bit): -
- Real-Time Clock: -
- CPU Maximum Speed: 48MHz
- GPIO Ports Number: 51
- Low-Voltage Detect: Yes
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: DMA;PWM;WDT
- Program Memory Type: FLASH
- Direct Memory Access: Yes
- Program Storage Size: 128KB
- Universal Serial Bus: Yes
- communication protocol: -
- Operating Voltage Range: 2V~3.6V
- Infrared Data Association: Yes
- Operating Temperature Range: -40°C~+85°C
- Secure Digital Input and Output: -
- Package: LQFP-64(10x10)
- Manufacturer: STMicroelectronics
- Series: STM32F1
- Packaging: Tray
- Part Status: Active
- Core Processor: ARM® Cortex®-M3
- Core Size: 32-Bit
- Speed: 48MHz
- Connectivity: I²C, IrDA, LINbus, SPI, UART/USART, USB
- Peripherals: DMA, PDR, POR, PVD, PWM, Temp Sensor, WDT
- Number of I/O: 51
- Program Memory Size: 128KB (128K x 8)
- EEPROM Size: -
- Voltage - Supply (Vcc/Vdd): 2V ~ 3.6V
- Data Converters: A/D 16x12b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 64-LQFP
- Base Part Number: STM32F102
- detail: ARM® Cortex®-M3 STM32F1 Microcontroller IC 32-Bit 48MHz 128KB (128K x 8) FLASH
