دیتاشیت TPS728120150DRVT
مشخصات دیتاشیت
| نام دیتاشیت | TPS728xx Series |
|---|---|
| حجم فایل | 1274.872 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 26 |
دانلود دیتاشیت TPS728xx Series |
TPS728xx Series Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments TPS728120150DRVT
- Output Current: 200mA
- Output Voltage: 1.2V;1.5V
- Dropout Voltage: 0.4V@(200mA)
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 6.5V
- Operating Temperature: -40°C~+125°C
- Quiescent Current (Ground Current): 80uA
- Package: DFN-6(2x2)
- Manufacturer: Texas Instruments
- Series: -
- Voltage - Output (Max): -
- Output Configuration: Positive
- Output Type: Fixed
- Voltage Dropout (Max): 0.4V @ 200mA
- Packaging: Cut Tape (CT)
- Voltage - Output (Min/Fixed): 1.2V, 1.5V
- Protection Features: Over Current, Over Temperature, Under Voltage Lockout (UVLO)
- PSRR: 65dB ~ 40dB (100Hz ~ 100kHz)
- Supplier Device Package: 6-WSON (2x2)
- Current - Quiescent (Iq): 80µA
- Base Part Number: TPS728
- Mounting Type: Surface Mount
- Number of Regulators: 1
- Voltage - Input (Max): 6.5V
- Current - Output: 200mA
- Part Status: Active
- Current - Supply (Max): 120µA
- Control Features: Enable
- Package / Case: 6-WDFN Exposed Pad
- detail: Linear Voltage Regulator IC 1 Output 200mA 6-WSON (2x2)
