STTH20002TV1 دیتاشیت

STTH20002TV1

مشخصات دیتاشیت

نام دیتاشیت STTH20002TV1
حجم فایل 64.294 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

مشاهده دیتاشیت STTH20002TV1

دانلود دیتاشیت

سایر مستندات

STTH20002TV 5 pages

مشخصات فنی

  • RoHS: true
  • Category: Diodes/Diodes - Fast Recovery Rectifiers
  • Datasheet: STMicroelectronics STTH20002TV1
  • Diode Configuration: 2 Independent
  • Reverse Voltage (Vr): 200V
  • Operating Temperature: +150°C@(Tj)
  • Forward Voltage (Vf@If): 1.2V@200A
  • Reverse Leakage Current: 100uA@200V
  • Reverse Recovery Time (trr): 41ns
  • Average Rectified Current (Io): 120A
  • Package: ISOTOP
  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 200V
  • Current - Average Rectified (Io) (per Diode): 120A
  • Voltage - Forward (Vf) (Max) @ If: 1.05V @ 100A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 100µA @ 200V
  • Operating Temperature - Junction: 150°C (Max)
  • Mounting Type: Chassis Mount
  • Package / Case: ISOTOP
  • Supplier Device Package: ISOTOP®
  • Base Part Number: STTH2
  • detail: Diode Array 2 Independent Standard 200V 120A Chassis Mount ISOTOP
