A1P50S65M2 دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت A1P50S65M2	دانلود دیتاشیت

Manufacturer: STMicroelectronics
Series: -
Packaging: Tray
Part Status: Active
IGBT Type: Trench Field Stop
Configuration: Three Phase Inverter
Voltage - Collector Emitter Breakdown (Max): 650V
Current - Collector (Ic) (Max): 50A
Power - Max: 208W
Vce(on) (Max) @ Vge, Ic: 2.3V @ 15V, 50A
Current - Collector Cutoff (Max): 100µA
Input Capacitance (Cies) @ Vce: 4150pF @ 25V
Input: Standard
NTC Thermistor: Yes
Operating Temperature: -40°C ~ 150°C (TJ)
Mounting Type: Chassis Mount
Package / Case: Module
Supplier Device Package: ACEPACK™ 1
Base Part Number: A1P50S65
detail: IGBT Module Trench Field Stop Three Phase Inverter 650V 50A 208W Chassis Mount ACEPACK™ 1
