TPS79118DBVR دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت TPS79118DBVR	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/Linear Voltage Regulators (LDO)
Datasheet: Texas Instruments TPS79118DBVR
Output Current: 100mA
Output Voltage: 1.8V
Output Polarity: positive
Number of Outputs: 1
Maximum Input Voltage: 5.5V
Operating Temperature: -40°C~+85°C
Quiescent Current (Ground Current): 250uA
Package: SOT-23-5
Manufacturer: Texas Instruments
Base Part Number: TPS791
Supplier Device Package: SOT-23-5
Voltage - Output (Max): -
Output Configuration: Positive
Current - Quiescent (Iq): 250µA
Output Type: Fixed
PSRR: 80dB ~ 45dB (100Hz ~ 100kHz)
Voltage Dropout (Max): -
Number of Regulators: 1
Mounting Type: Surface Mount
Packaging: Cut Tape (CT)
Voltage - Output (Min/Fixed): 1.8V
Protection Features: Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
Series: -
Voltage - Input (Max): 5.5V
Current - Output: 100mA
Part Status: Active
Package / Case: SC-74A, SOT-753
Control Features: Enable
detail: Linear Voltage Regulator IC 1 Output 100mA SOT-23-5
