ESDAULC5-1BF4 数据手册
其他文档
ESDAULC5-1BF4 12 pages
技术规格
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
- Datasheet: STMicroelectronics ESDAULC45-1BF4
- Clamping Voltage@Ipp: 13.5V
- Operating Temperature: -40°C~+150°C@(Tj)
- Breakdown Voltage (VBR): 5.8V
- Peak Pulse Power(Ppp)@8/20us: 140W
- Junction Capacitance(Cj)@1MHz: -
- Peak Pulse Current(Ipp)@8/20us: 10A@(8/20us)
- Reverse Stand-Off Voltage (Vrwm): 3V
- Package: 0201
- Manufacturer: STMicroelectronics
- Series: ESDA
- Packaging: Cut Tape (CT)
- Part Status: Active
- Type: Zener
- Bidirectional Channels: 1
- Voltage - Reverse Standoff (Typ): 3V
- Voltage - Breakdown (Min): 5.8V
- Voltage - Clamping (Max) @ Ipp: 13.5V (Typ)
- Current - Peak Pulse (10/1000µs): 10A (8/20µs)
- Power - Peak Pulse: 140W
- Power Line Protection: No
- Applications: General Purpose
- Capacitance @ Frequency: -
- Mounting Type: Surface Mount
- Package / Case: 0201 (0603 Metric)
- Supplier Device Package: 0201
- Base Part Number: ESDAULC45
- detail: 13.5V (Typ) Clamp 10A (8/20µs) Ipp Tvs Diode Surface Mount 0201
