دیتاشیت LM3676SD-3.3/NOPB
مشخصات دیتاشیت
| نام دیتاشیت | LM3676 |
|---|---|
| حجم فایل | 4323.719 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 27 |
دانلود دیتاشیت LM3676 |
LM3676 Datasheet |
|---|
مشخصات
- Package / Case: 8-WFDFN Exposed Pad
- Function: Step-Down
- Output Configuration: Positive
- Topology: Buck
- Base Part Number: LM3676
- Packaging: Cut Tape (CT)
- Operating Temperature: -30°C ~ 85°C (TA)
- Frequency - Switching: 2MHz
- Supplier Device Package: 8-WSON (3x3)
- Part Status: Obsolete
- Current - Output: 600mA
- Number of Outputs: 1
- Series: -
- Manufacturer: Texas Instruments
- Voltage - Input (Max): 5.5V
- Synchronous Rectifier: Yes
- Voltage - Output (Min/Fixed): 3.3V
- Voltage - Input (Min): 2.9V
- Mounting Type: Surface Mount
- Voltage - Output (Max): -
- Output Type: Fixed
- detail: Buck Switching Regulator IC Positive Fixed 3.3V 1 Output 600mA 8-WFDFN Exposed Pad
