دیتاشیت LM1117LDX-1.8/NOPB

LM1117-N, 1117I Series

مشخصات دیتاشیت

نام دیتاشیت LM1117-N, 1117I Series
حجم فایل 2940.079 کیلوبایت
نوع فایل pdf
تعداد صفحات 41

دانلود دیتاشیت LM1117-N, 1117I Series

LM1117-N, 1117I Series Datasheet

مشخصات

  • Control Features: -
  • Base Part Number: LM1117
  • Package / Case: 8-WDFN Exposed Pad
  • Current - Supply (Max): 10mA
  • Part Status: Obsolete
  • Current - Output: 800mA
  • PSRR: 75dB (120Hz)
  • Series: -
  • Voltage - Output (Min/Fixed): 1.8V
  • Mounting Type: Surface Mount
  • Number of Regulators: 1
  • Current - Quiescent (Iq): 5mA
  • Output Configuration: Positive
  • Voltage Dropout (Max): 1.2V @ 800mA
  • Operating Temperature: 0°C ~ 125°C
  • Supplier Device Package: 8-WSON (4x4)
  • Protection Features: Over Current, Over Temperature
  • Manufacturer: Texas Instruments
  • Voltage - Input (Max): 15V
  • Output Type: Fixed
  • Packaging: Cut Tape (CT)
  • Voltage - Output (Max): -
  • detail: Linear Voltage Regulator IC 1 Output 800mA 8-WSON (4x4)
