TPS51117RGYR دیتاشیت

TPS51117RGYR

مشخصات دیتاشیت

نام دیتاشیت TPS51117RGYR
حجم فایل 98.186 کیلوبایت
نوع فایل pdf
تعداد صفحات 33

مشاهده دیتاشیت TPS51117RGYR

دانلود دیتاشیت

سایر مستندات

TPS51117 33 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/DC-DC Controllers
  • Function: Step-down type
  • Topology: Step-down
  • Datasheet: Texas Instruments TPS51117RGYR
  • Input Voltage: 4.5V~5.5V
  • Duty Cycle (Max): -
  • Number of Outputs: 1
  • Switching Frequency: -
  • Operating Temperature: -40°C~+85°C@(TA)
  • Synchronous Rectification: Yes
  • Package: QFN-14-EP(4x4)
  • Manufacturer: Texas Instruments
  • Output Phases: 1
  • Series: D-CAP™
  • Output Configuration: Positive
  • Output Type: Transistor Driver
  • Clock Sync: No
  • Packaging: Cut Tape (CT)
  • Synchronous Rectifier: Yes
  • Voltage - Supply (Vcc/Vdd): 4.5V ~ 5.5V
  • Supplier Device Package: 14-VQFN (3.5x3.5)
  • Serial Interfaces: -
  • Frequency - Switching: -
  • Mounting Type: Surface Mount
  • Base Part Number: TPS511
  • Part Status: Active
  • Control Features: Enable, On Time Control, Power Good
  • Package / Case: 14-VFQFN Exposed Pad
  • detail: Buck Regulator Positive Output Step-Down DC-DC Controller IC 14-VQFN (3.5x3.5)
