دیتاشیت TPS7B8133QDRVRQ1
مشخصات دیتاشیت
| نام دیتاشیت | TPS7B81-Q1 Datasheet |
|---|---|
| حجم فایل | 2672.596 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 36 |
دانلود دیتاشیت TPS7B81-Q1 Datasheet |
TPS7B81-Q1 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments TPS7B8133QDRVRQ1
- Output Current: 150mA
- Output Voltage: 3.3V
- Dropout Voltage: 0.675V@(150mA)
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 40V
- Operating Temperature: -40°C~+125°C@(Ta)
- Quiescent Current (Ground Current): 3.5uA
- Power Supply Rejection Ratio (PSRR): 60dB@(100Hz)
- Package: DFN-6(2x2)
- Manufacturer: Texas Instruments
- Base Part Number: TPS7B8
- Supplier Device Package: 6-WSON (2x2)
- Voltage - Output (Max): -
- Output Configuration: Positive
- Current - Quiescent (Iq): 3.5µA
- Output Type: Fixed
- PSRR: 60dB (100Hz)
- Voltage Dropout (Max): 0.675V @ 150mA, 0.585V @ 150mA
- Number of Regulators: 1
- Mounting Type: Surface Mount
- Packaging: Cut Tape (CT)
- Voltage - Output (Min/Fixed): 3.3V, 5V
- Protection Features: Over Current, Over Temperature, Short Circuit
- Series: Automotive, AEC-Q100
- Voltage - Input (Max): 40V
- Current - Output: 150mA
- Part Status: Active
- Package / Case: 6-WDFN Exposed Pad
- Control Features: Enable
- detail: Linear Voltage Regulator IC 1 Output 150mA 6-WSON (2x2)
