VNHD7012AY Datasheet دیتاشیت

VNHD7012AY Datasheet

مشخصات دیتاشیت

نام دیتاشیت VNHD7012AY Datasheet
حجم فایل 1254.47 کیلوبایت
نوع فایل pdf
تعداد صفحات 43

مشاهده دیتاشیت VNHD7012AY Datasheet

دانلود دیتاشیت

سایر مستندات

VNHD7012AYTR 43 pages

مشخصات فنی

  • RoHS: true
  • Type: Brush DC Motor
  • Category: Power Supply Chip/Motor Driver ICs
  • Datasheet: STMicroelectronics VNHD7012AYTR
  • Interface: PWM
  • Output Current: 38A
  • Supply Voltage: 4V~28V
  • Operating Temperature: -40°C~+150°C@(Tj)
  • Package: PowerSSO-36
  • Manufacturer: STMicroelectronics
  • Series: Automotive, AEC-Q100, VIPOWER™
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Motor Type - Stepper: -
  • Motor Type - AC, DC: Brushed DC
  • Function: Driver
  • Output Configuration: Half Bridge (4)
  • Technology: CMOS, Power MOSFET
  • Step Resolution: -
  • Applications: Automotive
  • Current - Output: 38A
  • Voltage - Supply: 4V ~ 28V
  • Voltage - Load: 4V ~ 28V
  • Mounting Type: Surface Mount
  • Package / Case: 36-PowerFSOP (0.295", 7.50mm Width)
  • Supplier Device Package: PowerSSO-36
  • Base Part Number: VNHD7012
  • detail: Motor Driver CMOS, Power MOSFET PWM PowerSSO-36
