- Datasheet TPS54334 Datasheet
TPS54334 Datasheet Datasheet
Datasheet specifications
| Datasheet's name | TPS54334 Datasheet |
|---|---|
| File size | 3148.041 KB |
| File type | |
| Number of pages | 39 |
Download Datasheet TPS54334 Datasheet |
Download Datasheet |
|---|
Other documentations
TPS54334DRCR 37 pages
Technical specifications
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Step-down type
- Topology: Step-down
- Datasheet: Texas Instruments TPS54334DDAR
- Output Type: Adjustable
- Input Voltage: 4.2V~28V
- Output Voltage: 0.8V~24V
- Number of Outputs: 1
- Switching Frequency: 570kHz
- Output Current (Max): 3A
- Operating Temperature: -40°C~+85°C@(TA)
- Synchronous Rectification: Yes
- Package: SOP-8
- Manufacturer: Texas Instruments
- Supplier Device Package: 8-SO PowerPad
- Voltage - Input (Min): 4.2V
- Voltage - Output (Max): 24V
- Output Configuration: Positive
- Mounting Type: Surface Mount
- Current - Output: 3A
- Synchronous Rectifier: Yes
- Frequency - Switching: 570kHz
- Packaging: Cut Tape (CT)
- Voltage - Output (Min/Fixed): 0.8V
- Series: -
- Base Part Number: TPS543
- Voltage - Input (Max): 28V
- Part Status: Active
- Package / Case: 8-PowerSOIC (0.154", 3.90mm Width)
- detail: Buck Switching Regulator IC Positive Adjustable 0.8V 1 Output 3A 8-PowerSOIC (0.154", 3.90mm Width)
