Z0107DA 2AL2 数据手册
其他文档
未找到其他文档！
技术规格
- Manufacturer: STMicroelectronics
- Series: -
- Packaging: Tape & Box (TB)
- Part Status: Active
- Triac Type: Logic - Sensitive Gate
- Voltage - Off State: 400V
- Current - On State (It (RMS)) (Max): 800mA
- Voltage - Gate Trigger (Vgt) (Max): 1.5V
- Current - Non Rep. Surge 50, 60Hz (Itsm): 8A, 8.5A
- Current - Gate Trigger (Igt) (Max): 5mA
- Current - Hold (Ih) (Max): 10mA
- Configuration: Single
- Operating Temperature: -40°C ~ 125°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-226-3, TO-92-3 (TO-226AA)
- Supplier Device Package: TO-92
- Base Part Number: Z0107
- detail: TRIAC Logic - Sensitive Gate 400V 800mA Through Hole TO-92
