PM6644TR دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت PM6644TR	دانلود دیتاشیت

PM6644 35 pages

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: Step-down
Datasheet: STMicroelectronics PM6644TR
Output Type: 可调和固定
Input Voltage: 4.5V~25V
Output Voltage: 0.9V~8V
Number of Outputs: 1
Switching Frequency: 600kHz
Output Current (Max): 350mA
Operating Temperature: -40°C~+125°C@(TJ)
Synchronous Rectification: Yes
Package: DFN-10(3x3)
Manufacturer: STMicroelectronics
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Output Configuration: Positive
Voltage - Input (Min): 4.5V
Voltage - Input (Max): 25V
Voltage - Output (Min/Fixed): 0.9V (3.47V)
Voltage - Output (Max): 8V
Current - Output: 350mA
Frequency - Switching: 200kHz ~ 600kHz
Synchronous Rectifier: Yes
Mounting Type: Surface Mount
Package / Case: 10-VFDFN Exposed Pad
Supplier Device Package: 10-DFN (3x3)
Base Part Number: PM6644
detail: Buck Switching Regulator IC Positive Adjustable (Fixed) 0.9V (3.47V) 1 Output 350mA 10-VFDFN Exposed Pad
