دیتاشیت TPS2064DGNR
مشخصات دیتاشیت
| نام دیتاشیت |
TPS2064DGNR
|
| حجم فایل |
117.36
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
40
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Power Distribution Switches
-
Datasheet:
Texas Instruments TPS2064DGNR
-
Input Voltage:
2.7V~5.5V
-
Output Current:
1.5A
-
Number of Outputs:
2
-
Resistor On-State:
70mΩ
-
Operating Temperature -:
0°C~+105°C
-
Package:
MSOP-8
-
Manufacturer:
Texas Instruments
-
Series:
-
-
Output Configuration:
High Side
-
Output Type:
N-Channel
-
Fault Protection:
Current Limiting (Fixed), Over Temperature, Reverse Current, UVLO
-
Packaging:
Cut Tape (CT)
-
Ratio - Input:Output:
1:2
-
Input Type:
Non-Inverting
-
Current - Output (Max):
1.5A
-
Voltage - Supply (Vcc/Vdd):
Not Required
-
Switch Type:
General Purpose
-
Supplier Device Package:
8-MSOP-PowerPad
-
Base Part Number:
TPS206
-
Features:
Status Flag
-
Voltage - Load:
2.7V ~ 5.5V
-
Interface:
On/Off
-
Rds On (Typ):
70mOhm
-
Mounting Type:
Surface Mount
-
Package / Case:
8-TSSOP, 8-MSOP (0.118", 3.00mm Width) Exposed Pad
-
Part Status:
Active
-
Operating Temperature:
0°C ~ 105°C (TJ)
-
detail:
Power Switch/Driver 1:2 N-Channel 1.5A 8-MSOP-PowerPad
