دیتاشیت EMIF06-HMC02F2
مشخصات دیتاشیت
نام دیتاشیت |
EMIF06-HMC02F2
|
حجم فایل |
286.829
کیلوبایت
|
نوع فایل |
pdf
|
تعداد صفحات |
7
|
مشخصات
-
Manufacturer:
STMicroelectronics
-
Series:
EMIF
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Active
-
Type:
Low Pass
-
Filter Order:
2nd
-
Technology:
RC (Pi)
-
Number of Channels:
6
-
Center / Cutoff Frequency:
300MHz (Cutoff)
-
Attenuation Value:
-30dB @ 900MHz
-
Resistance - Channel (Ohms):
50
-
Values:
R = 50Ohms, C = 20pF
-
ESD Protection:
Yes
-
Operating Temperature:
-40°C ~ 85°C
-
Applications:
General Purpose
-
Voltage - Rated:
-
-
Mounting Type:
Surface Mount
-
Package / Case:
16-WFBGA, FCBGA
-
Size / Dimension:
0.074" L x 0.074" W (1.88mm x 1.88mm)
-
Height:
0.028" (0.71mm)
-
Base Part Number:
EMIF06
-
detail:
RC (Pi) EMI Filter 2nd Order Low Pass 6 Channel R = 50Ohms, C = 20pF 16-WFBGA, FCBGA
