TPS54627DDAR دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت TPS54627DDAR	دانلود دیتاشیت

TPS54627 25 pages

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: Step-down
Datasheet: Texas Instruments TPS54627DDAR
Output Type: Adjustable
Input Voltage: 4.5V~18V
Output Voltage: 0.765V~5.5V
Number of Outputs: 1
Switching Frequency: 650kHz
Output Current (Max): 6A
Operating Temperature: -40°C~+85°C@(TA)
Synchronous Rectification: Yes
Package: SO-8-EP
Manufacturer: Texas Instruments
Supplier Device Package: 8-SO PowerPad
Voltage - Input (Min): 4.5V
Voltage - Output (Max): 5.5V
Output Configuration: Positive
Mounting Type: Surface Mount
Current - Output: 6A
Synchronous Rectifier: Yes
Frequency - Switching: 650kHz
Packaging: Cut Tape (CT)
Voltage - Output (Min/Fixed): 0.765V
Series: D-CAP2™
Base Part Number: TPS546
Voltage - Input (Max): 18V
Part Status: Active
Package / Case: 8-PowerSOIC (0.154", 3.90mm Width)
detail: Buck Switching Regulator IC Positive Adjustable 0.765V 1 Output 6A 8-PowerSOIC (0.154", 3.90mm Width)
