دیتاشیت LP38502TJ-ADJ/NOPB
مشخصات دیتاشیت
| نام دیتاشیت | LP38500/2-ADJ, LP38500A/2A-ADJ |
|---|---|
| حجم فایل | 1540.475 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 30 |
دانلود دیتاشیت LP38500/2-ADJ, LP38500A/2A-ADJ |
LP38500/2-ADJ, LP38500A/2A-ADJ Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments LP38502TJ-ADJ/NOPB
- Output Type: Adjustable
- Output Current: 1.5A
- Output Voltage: 0.6V~5V
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 5.5V
- Operating Temperature: -40°C~+125°C
- Quiescent Current (Ground Current): 15uA
- Package: TO-263-5
- Manufacturer: Texas Instruments
- Series: -
- Voltage - Output (Max): 5V
- Output Configuration: Positive
- Voltage Dropout (Max): 0.37 @ 1.5A
- Packaging: Cut Tape (CT)
- Voltage - Output (Min/Fixed): 0.6V
- Protection Features: Over Current, Over Temperature, Short Circuit
- PSRR: 58dB ~ 56dB (120Hz ~ 1kHz)
- Supplier Device Package: TO-263-5 Thin
- Current - Quiescent (Iq): 15µA
- Base Part Number: LP38502
- Mounting Type: Surface Mount
- Number of Regulators: 1
- Voltage - Input (Max): 5.5V
- Current - Output: 1.5A
- Part Status: Active
- Current - Supply (Max): 4mA
- Control Features: Enable
- Package / Case: TO-263-5 Thin
- detail: Linear Voltage Regulator IC 1 Output 1.5A TO-263-5 Thin
