TPS61176RTER دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
TPS61176RTER
|
|
حجم فایل
|
110.473
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
34
|
مشخصات فنی
-
RoHS:
true
-
Type:
DC-DCVoltage Stabilizer
-
Dimming:
Analog;PWM
-
Category:
Nixie Tube Driver/LED Driver/LED Drivers
-
Channels:
6
-
Topology:
boost converter
-
Datasheet:
Texas Instruments TPS61176RTER
-
Input Voltage:
2.7V~6.5V
-
Output Current:
35mA
-
Output Voltage:
38V
-
Switch Frequency:
1MHz
-
Operating temperature:
-40°C~+85°C
-
Package:
QFN-16-EP(3x3)
-
Manufacturer:
Texas Instruments
-
Current - Output / Channel:
35mA
-
Internal Switch(s):
Yes
-
Supplier Device Package:
16-WQFN (3x3)
-
Voltage - Supply (Min):
2.7V
-
Applications:
Backlight
-
Voltage - Supply (Max):
6.5V
-
Mounting Type:
Surface Mount
-
Base Part Number:
TPS611
-
Packaging:
Cut Tape (CT)
-
Voltage - Output:
38V
-
Series:
-
-
Package / Case:
16-WFQFN Exposed Pad
-
Number of Outputs:
6
-
Part Status:
Active
-
Frequency:
1MHz
-
detail:
LED Driver IC 6 Output DC DC Regulator Step-Up (Boost) Analog, PWM Dimming 35mA 16-WQFN (3x3)
