ESDAVLC5-4BX4 数据手册
其他文档
未找到其他文档！
技术规格
- Manufacturer: STMicroelectronics
- Series: ESDA, TRANSIL™
- Packaging: Cut Tape (CT)
- Part Status: Discontinued at Digi-Key
- Type: Steering (Rail to Rail)
- Unidirectional Channels: 4
- Voltage - Reverse Standoff (Typ): 3V
- Voltage - Breakdown (Min): 5.5V
- Voltage - Clamping (Max) @ Ipp: 18V
- Current - Peak Pulse (10/1000µs): 1A (8/20µs)
- Power - Peak Pulse: 30W
- Power Line Protection: No
- Applications: General Purpose
- Capacitance @ Frequency: -
- Operating Temperature: -30°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 4-Micro-X
- Supplier Device Package: 4-Micro-X
- Base Part Number: ESDAVLC5
- detail: 18V Clamp 1A (8/20µs) Ipp Tvs Diode Surface Mount 4-Micro-X
