74ACT16374DLR دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت 74ACT16374DLR	دانلود دیتاشیت

RoHS: true
Type: D-Type
Series: 74ACT
Category: Logic ICs/Flip Flops
Datasheet: Texas Instruments 74ACT16374DLR
Output Type: Tri-State;Non-Inverted
Sink Current: 24mA
Trigger Type: 上升沿
Source Current: 24mA
Supply Voltage: 4.5V~5.5V
Clock Frequency: 65MHz
Input Capacitance: 4.5pF
Number of Elements: 2
Operating Temperature: -40°C~+85°C
Quiescent Current (Iq): 8uA
Maximum Propagation Delay: 8.8ns@5V,50pF
Number of Bits per Element: 8
Package: SSOP-48-300mil
Manufacturer: Texas Instruments
Function: Standard
Supplier Device Package: 48-SSOP
Current - Output High, Low: 24mA, 24mA
Voltage - Supply: 4.5V ~ 5.5V
Current - Quiescent (Iq): 8µA
Mounting Type: Surface Mount
Packaging: Cut Tape (CT)
Max Propagation Delay @ V, Max CL: 8.8ns @ 5V, 50pF
Base Part Number: 74ACT1
Part Status: Active
Package / Case: 48-BSSOP (0.295", 7.50mm Width)
detail: Flip Flop 2 Element D-Type 8 Bit Positive Edge 48-BSSOP (0.295", 7.50mm Width)
