TPS27S100APWPR دیتاشیت

TPS27S100APWPR

مشخصات دیتاشیت

نام دیتاشیت TPS27S100APWPR
حجم فایل 76.948 کیلوبایت
نوع فایل pdf
تعداد صفحات 41

دانلود دیتاشیت TPS27S100APWPR

دانلود دیتاشیت

سایر مستندات

TPS27S100x Datasheet 40 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Power Distribution Switches
  • Datasheet: Texas Instruments TPS27S100APWPR
  • Package: TSSOP-14-EP
  • Manufacturer: Texas Instruments
  • Series: Automotive, AEC-Q100
  • Output Configuration: High Side
  • Output Type: N-Channel
  • Fault Protection: Over Load, Over Temperature, Short Circuit, UVLO
  • Packaging: Cut Tape (CT)
  • Ratio - Input:Output: 1:1
  • Input Type: Non-Inverting
  • Current - Output (Max): 13A
  • Voltage - Supply (Vcc/Vdd): Not Required
  • Switch Type: Relay, Solenoid Driver
  • Supplier Device Package: 14-HTSSOP
  • Base Part Number: TPS27S
  • Features: Shutdown
  • Voltage - Load: 40V
  • Interface: Logic
  • Rds On (Typ): 80mOhm
  • Mounting Type: Surface Mount
  • Package / Case: 14-PowerTSSOP (0.173", 4.40mm Width)
  • Number of Outputs: 1
  • Part Status: Active
  • Operating Temperature: -40°C ~ 125°C (TA)
  • detail: Power Switch/Driver 1:1 N-Channel 13A 14-HTSSOP
