دیتاشیت Power Management Guide

Power Management Guide

مشخصات دیتاشیت

نام دیتاشیت Power Management Guide
حجم فایل 6420.273 کیلوبایت
نوع فایل pdf
تعداد صفحات 93

Power Management Guide

دانلود دیتاشیت

سایر مستندات

TPS2021D 30 pages

TPS2020 - TPS2024 Datasheet 29 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Power Distribution Switches
  • Datasheet: Texas Instruments TPS2023DR
  • Input Voltage: 2.7V~5.5V
  • Output Current: 1.5A
  • Number of Outputs: 1
  • Resistor On-State: 33mΩ
  • Operating Temperature -: -40°C~+125°C
  • Package: SOP-8
  • Manufacturer: Texas Instruments
  • Series: -
  • Output Configuration: High Side
  • Output Type: N-Channel
  • Fault Protection: Current Limiting (Fixed), Over Temperature, UVLO
  • Packaging: Cut Tape (CT)
  • Ratio - Input:Output: 1:1
  • Input Type: Non-Inverting
  • Current - Output (Max): 1.5A
  • Voltage - Supply (Vcc/Vdd): Not Required
  • Switch Type: General Purpose
  • Supplier Device Package: 8-SOIC
  • Base Part Number: TPS202
  • Features: Status Flag
  • Voltage - Load: 2.7V ~ 5.5V
  • Interface: On/Off
  • Rds On (Typ): 33mOhm
  • Mounting Type: Surface Mount
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Part Status: Active
  • Operating Temperature: -40°C ~ 125°C (TJ)
  • detail: Power Switch/Driver 1:1 N-Channel 1.5A 8-SOIC
